Olympus CH2 Series - Disassembly of rack and pinion

4-10. Remove plate (AA7830001 by removing 3
screws (CSTB3 xlOSA).
4-l 1. Remove the gears.
[r
AA783300
AA783400
c
AA783400
A8467000
C
AA787800
AA787900
5.
Diisassembly of rack and pinion
5-l. Place tools KG2010 and KKAA7828 on the
right gear (AA782700) and the left nut
(AA782800) respectively, then rotate them
counter-clockwise and remove the nut.
*The nut is fixed with glue.
*Balls B1/16 are held in the bearing, be care-
full not to lose them.
-17-
