Olympus CKX53 - Fluorescence Set

9
CKX53
2-2 Fluorescence set
The numbers assigned to operating portions indicate operating portions described in "9-2 Summary of
fluorescence observation procedures" (page 48).
TIP
Main switch 1
Revolving nosepiece 4
Coarse focusing knob …
Collector lens focusing knob
Umbra shield
(ambient light shieldingplate)
2
Field iris diaphragm
centering knob
Field iris diaphragm lever
8
Filter slider for reflected light illumination 5
Burner
centering
knobs
Mirror focusing screw
(Back of lamp housing)
Camera Adapter
fixing knob
Fine focusing knob
†
Main switch 1
(back of light source)
X-axis knob 9
Y-axis knob a
Light path selection
lever
For details, see the instruction
manual provided with U-RFL-T.
TIP
For details, see the instruction
manual provided with U-HGLGPS.
TIP
Fluorescence mirror
unit selection lever
3
