Olympus CKX53 - Cleaning and Sterilizing Around the Stage; Procedures to Place Specimens; Placing the Container on the Stage; When Using the Optional Stage Unit

11
CKX53
Useful information
The AC adapter
e
can be hung on the hook
f
on the
back of the microscope frame CKX53SF.
Bundling the AC adapter cord
g
with the provided tie wrap
clears the space on the back of the microscope frame.
TIP
3
Cleaning and sterilizing around the stage
When using the Fluorescence set, the AC adapter cannot be
hung on the hook.
TIP
Refer to
Decontamination
(page 6).
e
f
g
3-2 Procedures to place specimens
1
Placing the container on the stage
Place the container directly on the plain stage.
Or put the container on the specimen holder and place it on the plain stage.
1
2
When using the optional stage unit
Specimen holder and mechanical stage CKX3-MVR
Place the container on the specimen holder (option).
For containers and specimen holders corresponding to
containers, see page 23.
Place the specimen holder (option) on the stage.
· When using the mechanical stage CKX3-MVR (option), place
the specimen holder (option)
b
so that it fits within the holder
portion
a
.
· When using the micro plate, the micro plate can be placed
directly on the holder portion
a
.
1
TIP
2
TIP
Holder portion of the mechanical stage CKX3-MVR
The holder portion
a
of the mechanical stage can be escaped from the
stage top as shown in the picture.
In case that the holder portion
a
is not necessary, such as when
placing the large container on the stage, etc., escape the holder portion.
The holder portion
a
is detachable. For procedures to attach/detach the
holder portion, see page 39.
a
b
a
