Olympus CKX53 - Specifications and Assembly; Technical Specifications

28
Item Specifications
Bright Field Set Phase Contrast
Entry Set
Phase Contrast
Standard Set
Fluorescence Set
Optical system UIS2 optical system
Applicable observation method Bright field Bright field, Phase contrast Bright field, Phase
contrast, Fluorescence
Dimensions (D x W x H) 504 mm x
200 mm x
454 mm
504 mm x
355 mm x
454 mm
667 mm x
355 mm x
454 mm
Other major dimensions Stage surface height: 195 mm
Eye point height: 391 mm or 348 mm (
)
Upper side or lower side of interpupillary distance 62 mm
Weight 6.9 kg 7.1 kg 8.4 kg 12.5 kg
(Excluding U-RFL-T)
Microscope
frame
CKX53SF
Focusing
portion
Mechanism Revolving nosepiece vertical movement mechanism using the coarse and fine
focusing knobs
Working range 20 mm (Focal point: up to 18.5 mm from the plain stage top surface)
Working
distance
Fine focusing knob: 0.3 mm / rotation
Coarse focusing knob: 36.8 mm / rotation
Revolving nosepiece 4 positions
Tube portion Type Trinocular tube
Interpupillary
distance
adjustment
range
48 mm - 75 mm
Eyepiece tilt
angle
45 °
Light path split
ratio
Visual light path 0% / Camera light path 100%, Visual light path 100% / Camera
light path 0%
Camera port Olympus camera adapter interface
Eyepiece Magnification 10X
Field number 22
Transmitted
light
illumination
Light source LED light source
Color
temperature
4000 K
Condenser
portion
Maximum
numeral
aperture (NA)
0.3
Applicable
objective
magnification
2X, 4X, 10X, 20X and 40X
Working
distance (W.D.)
72 mm
Aperture stop
(AS)
Diaphragm blade, manual open / close mechanism
Detachable
mechanism
Detachable by users; specimen maximum height when the condenser is
removed: 190 mm
Filter holder
Provided (supports up to filter thickness 6 mm)
Phase contrast
slider slot
The insertion direction can be adjusted by the range of ±30 degrees to right or left
sides.
Plain stage Surface size
to place
specimens
252 mm (D) x 200 mm (W) (Front side from the optical axis:119 mm)
Placeable
specimen
weight
5 kg or less
Stage center
plate
Various types of stage center plates are combinable. The transparent resin stage
center plate is provided as a standard.
6 Specifications
6-1 Sets with CKX53
