22
Fig. 5
Fig. 6
DP73
g
h
6
f
Installing the PCIe Extension Box (Fig. 6)
The PCIe extension box can be installed either horizontally or
vertically.
Horizontal Installation
Place the PCIe extension box on the desktop so that the surface
with rubber feet faces down.
Vertical Installation
Attach the provided plates
a
to the side panel of the extension
box using provided screws
b
.
a
b
To Next Page
