OM SYSTEM VN-541PC - Technical Specifications

6
Specications
40
EN
General items
4 Recording/Playback formats
WMA format
4 Sampling frequency
WMA 32 kbps 44.1 kHz
WMA 16 kbps 22.05 kHz
WMA 5 kbps* 8 kHz
* VN-541PC model only
4 Maximum working output
200 mW (8 Ω speaker)
4 Maximum output voltage
Recorder: â 150 mV
(according to EN 50332-2)
4 Recording media*
Internal NAND flash memory: 4 GB
* Some recording media memory
capacity is used as a management
area, so the actual usable capacity
will always be slightly less than the
displayed capacity.
4 Speaker
Built-in 20 mm diameter round dynamic
speaker
4 Microphone jack
3.5 mm diameter; Impedance: 2 kΩ
4 Earphones jack
3.5 mm diameter; Impedance: 8 Ω
minimum
4 Power source
Two AAA dry cell batteries (model LR03)
4 External dimensions
108 × 37.5 × 20 mm
(Not including largest projection)
4 Weight
67 g (including battery)
4 Operating temperature
0 to 42°C (32 to 107.6°F)
Frequency response
4 During recording
MEMO 200 Hz to 7 kHz
TALK 200 Hz to 13 kHz
MUSIC 40 Hz to 13 kHz
LP* 200 Hz to 3 kHz
* VN-541PC model only
4 During playback
20 Hz to 20 kHz
(The upper and lower limit values of the
frequency response depend on each
recording format.)
Specifications
