Omega C9000A SERIES User Manual

8
Figure 2-3. CN9000A, Rear View, Signal Connection
Designations
TERMINAL DESIGNATIONS AND SIGNAL CONNECTIONS
1 AC Power, 115 VAC 50/60 Hz (230 VAC, optional)
2 AC Power, Neutral
3RTD (black, if 3-wire RTD) (For T/C, do not use terminal.)
4 Thermocouple (-); or RTD (black if 3-wire RTD); or Neg.
Voltage
5 Thermocouple (+); or RTD (red, if 3-wire RTD); or Pos.
Voltage
6 Output 2 (SP2) Mechanical Relay Normally Open (N.O.)
7 Output 2 (SP2) Mechanical Relay Common (C.) or 5V Pulse (-)
8 Output 2 (SP2) Mechanical Relay Normally Closed (N.C.);
or 5V Pulse (+)
9 Output 1 (SP1) Mech Relay N.O.; 1 A SSR N.O.; 5V Pulse
(-); 0-10V (-); or 4-20 mA (-)
10 Output 1 (SP1) Mech Relay C.; 1A SSR C; 5V Pulse (+);
0-10 V (+); or 4-20 mA (+)
11 Output 1 (SP1) Mech Relay N.C.; or 1A SSR N.C.
Check side label on controller for supply voltage before wiring.
Your choice of thermocouple types J, K, T, E, R, S, N, B,
J DIN, and the Pt100 2-wire RTD inputs are selectable via the keys
on the CN91XXA version of the controller. The CN92XXA controller
is configured to accept a 3-wire RTD input only. Figure 2-4 shows
how to wire any of these sensor inputs to the controller.
91011 12
N.O. C. N.C. L N
-+ OV
+-
N.C. C. N.O. + -
876543
(Output 1) (Power)
(Output 2) (Input Signal)
1 A SSR, MECHANICAL RELAY
0-10V, 4-20 mA, SSD (PULSE)
SSD (PULSE)
MECHANICAL RELAY
CAUTION
