Omega C9000A SERIES User Manual

22
To display maximum allowable
setpoint:
To increase or decrease the
setpoint:
To stop changing the setpoint:
To get back to process temp
(exit Function/Option Program
Mode). The upper limit of the
allowable setpoint is now
changed.
4
5
6
7
1.
2.
3.
Press ★
Press and hold
in ★ and
simultaneously
press to increase
or to decrease
value
Release fingers
Press P
STEP ACTION DISPLAY
Initial Configuration:
Function .16 must be selected first followed by settings in
Functions .17-.24 if required, then exit from Programming
Mode before making further selections. (Press P)
If 20 seconds is not a suitable Proportional Cycle Time for the
process, the correct value for Function .4 can be preselected
before Autotune (AT).
Protected Functions:
All Functions (except user settings Functions .1, .2 and .3)
may be locked into memory after setting to prevent
tampering. Put small jumper socket beneath lower bezel to
left pair of pins (Section 3.13).
Locating Standard Functions:
Function .0 is the Function starting point. From there, you can
go up or down.
3.5.1.4 Details of Standard Functions .0-.25
NOTES
Press to increase.
Press to decrease: display jumps directly to Function .13 to
access the higher Functions. Press and hold to scroll through
to Function .0.
Refer to Section 3.12 for ADVANCED FUNCTIONS.
4. 0 0
5. 0 0
T E M P
