33
TABLE 3-4 (Cont'd)
FUNCTION
.19 (Cont'd) SP2 OPERATING MODE
Allows for selection of upscale or downscale protection for second
output.
Make the proper selection here in Function .19 before adjusting
SP2 in Function .2.
(Op#).(Fn#) Parameter/Comment
0.19 OUT
1.19 Deviation alarm-High (Above SP1)
2.19 Deviation alarm-Low (Below SP1)
3.19 Deviation band alarm (Out of Limits)
4.19 Full scale alarm-High (Non-tracking)
5.19 Full scale alarm-Low (Non-tracking)
6.19 LBA-Loop Break Alarm
7.19 Cool strategy
.20 SENSOR BREAK PROTECTION (OUTPUT 1)
.21 SENSOR BREAK PROTECTION (OUTPUT 2)
Allows for selection of upscale or downscale thermocouple break
protection for first setpoint so that output will be in safest state if
input is lost. Most heating applications require upscale protection.
(Op#).(Fn#) Parameter/Comment
0.20 SP1 output OFF (upscale)
1.20 SP1 output ON (downscale)
(Op#).(Fn#) Parameter/Comment
0.21 SP2 output OFF (upscale)
1.21 SP2 output ON (downscale)
