Omicron CMC 156 User Manual

Technical Data EP Option
51
.
0.0
5.0
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0
10.0 11.0 12.0
I in A
P in VA
Ptyp in [VA]
Pgar in [ VA]
Figure 18 Typical (Ptyp.) and guaranteed (Pguar.) output power of the
internal current amplifiers in the 12.5 A range for EP option.
For a parallel connection of three current outputs a maximum output power of
Pout > 80 VA
ac
is reached.
Figure 19 Typical (typ) and guaranteed (guar) output power of the current
outputs for single-phase operation in the 12.5 A range for EP
option (three outputs in parallel).
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
I in A
P in VA
1-ph. typ.
1 ph. gar.
