0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50 0.55 0.60 0.65 0.70 0.75 0.80 0.85 0.90 0.95 1.00 1.05 1.10 1.15 1.20 1.25
I in A
P in VA
Ptyp in [VA]
Pguar in [VA]
Figure 20 Typical (Ptyp.) and guaranteed (Pguar.) output power of the
internal current amplifiers in the 1.25 A range for option EP.
