CMC 353 Reference Manual
20
4.1 Block Diagram
Figure 4-1:
Main block diagram of the
CMC 353
DC
AC
Main Group
SELV Group
AUX DC
Internal
Supplies
VOLTAGE
CURRENT
CPU
System Control
(Signal Generator)
PE
Mains
Host
Interface
DC DC
reinforced isolation
reinforced isolation
r
e
i
n
f
o
r
c
e
d
i
s
o
l
a
t
i
o
n
PC
Ext.
Ampl.
Counter
1,2
Bin. Out
11...14
CMGPS
IRIG-B
3
421
BINARY OUTPUT
LL out
1-6
ext.
Interf.
10
9
8
65
43
2
1
BINARY INPUT
working isolation
Control
Control
Control AUX DC
VOLTAGE
OUTPUT
CURRENT
OUTPUT
3 x 0...32A
4 x 0...300V
0...264V
DC
working isolation
