CMC 353 Reference Manual
84
1. Flexible test lead adapter
5 cm (2") test lead adapter with retractable sleeve to connect the CMC 353
output to non-safety sockets in combination with a regular flexible 2 m (6 ft.)
test lead as shown at section 9.5.1.
Specification: 600 V/32 A
Amount: 6 x red, 6 x black
2. Flexible jumper
Flexible jumper to connect current outputs in parallel (up to 32 A) or to
short-out the neutrals of binary inputs. Identical to article of standard
delivery scope listed under 9.5.1.
Specification: 1000 V/32 A
Amount: 4 x black
3. Crocodile clamp
Crocodile clamps for secondary side to connect to pins or screw bolts.
Specification: 1000 V/32 A
Amount: 4 x red, 4 x black
