44
Configuring the post-trigger action
With the post-trigger action, you can configure what the device outputs when the recording has
finished.
Possible actions are sending a GOOSE message or setting a binary output to a certain value.
The GOOSE message can be used as a trigger input for another device.
To send a GOOSE message, select the appropriate port(s) and configure the GOOSE details. Ports A
and B cannot be used when they are in TAP mode.
To set a binary output to a certain level, select the binary output. The selected binary outputs are set
to true. When you select Inverted, the value is inverted (negative logic).
Storage location
In the Storage, you can define the location where to store the recording files. In addition to the
device’s internal disk, you can also use external storage devices such as USB flash drives or external
HDDs.
When you click a disk in the Drives section, the disk details and recording files on the disk become
available in the Details and the Recording sections, respectively.
To define the default storage disk, click the appropriate disk, and then click Use storage as default.
The default disk is used whenever it is connected and available; otherwise the internal disk is used.
To safely remove a disk, click the appropriate disk, and then click Safely remove disk.
