Omicron MPD 800 User Manual

OMICRON 51
MPD 800 measurement system
OMICRON 24 W DC supply
MPC1 measurement protection case (empty)
Note: MPC1 can be equipped with the following options:
A: 2 x MPD 800 with 2 x RBP1
B: 1 x MPD 800 with 1 x RBP1 and UHF 800 with RBP1
C: 1 x MPD 800 with 1 x RBP1 and CPL1
D: 1 x UHF 800 with RBP1
E: 1 x MPD 800 with 1 x RBP1
Flight case (MTC2) for MPD 800 system
MTC2 is the MPD flight case. It can contain:
3 x MPD 800 acquisition units or 3 x UHF 800
3 x CPL1
1 x CAL 542 or 1 x RIV1
1 x MCU2
3 x RBP1
Transport case (MTC1) for MPD 800 system
MTC1 is the universal MPD transport case and can
contain:
Option A:
5 x MPD 800 acquisition units
1 x UHF 800
1 x CAL 542
1 x RIV1
1 x MCU2
6 x RBP1
Option B:
3 x MPD 800 acquisition units
1 x UHF 800
1 x CAL 542
1 x RIV1
1 x MCU2
4 x RBP1
Table 2-9: Package content and delivery (continued)
Item

Omicron MPD 800 Specifications

General

Brand	Omicron
Model	MPD 800
Category	Test Equipment
Language	English
