Omicron MPD 800 User Manual

OMICRON 63
Technical specifications
3.6.3 Mechanical data
3.6.4 Environmental conditions
3.6.5 Standards
Table 3-19: Mechanical data
Parameter Value
Dimensions (W × D × H) 115 mm × 175 mm × 38 mm
(4.53inch×6.89inch×1.50inch)
Weight 910 g (2 lb)
Table 3-20: Environmental conditions
Parameter Value
Humidity 5 % … 85 %, non-condensing
Ambient temperature (operating/discharge) -20 °C … +55 °C
Ambient temperature (charge) 0 °C … +40 °C
Ambient temperature (storage) -20 °C … +30 °C
Maximum operating altitude 4000 m
Maximum storage altitude 12000 m
Ambient temperature OMICRON 24 W DC supply +10 °C … +55 °C
Table 3-21: Standards
Parameter Standard Value
EMC IEC/EN 61326-1 (industrial
electromagnetic environment)
FCC subpart B of part 15, class A
Safety IEC/EN/UL 61010-1
IEC/EN/UL 61010-2-030
Ingress protection
(connectors mated)
IEC/EN 60529 IP4x
