MPD 800 User Manual
62 OMICRON
3.6 RBP1 rechargeable battery pack
3.6.1 Device data
3.6.2 Power data
Table 3-17: Device data
Parameter Value
Output voltage OUTPUT 9 V…24 V DC
Output current OUTPUT
≤4A DC
1
1. Short-circuit protected. The current cannot be increased by multiple RBP1 devices.
Nominal battery voltage 11.1 V
Energy
(900 mA discharge current, 25 ºC ambient temperature)
80 Wh
Nominal energy
(theoretical value)
(96.6 Wh)
Charge cut-off voltage
2
2. Defined by internal charger circuitry. The charging process is stopped at the overcharge cut-off voltage.
12.5 V
Discharge cut-off voltage
3
3. Defined by internal charger circuitry. Discharging the RBP1 is stopped at the overdischarge cut-off voltage.
9V
Cell chemistry Lithium-ion
Battery life cycle
4
4. Whichever occurs first. Remaining 50 % SoH equals 40 Wh remaining energy.
1000 cycles or 5 years
Table 3-18: Power data
Parameter Value
Supply voltage INPUT input 9 V … 24 V DC ±5 %
Power consumption INPUT input:
Supply voltage ≤20 V
Supply voltage >20 V
≤24W
≤75W
Supply voltage OMICRON 24 W DC supply 100 V … 240 V
Supply voltage frequency range OMICRON 24 W DC supply 50 Hz … 60 Hz
