Omicron MPD 800 User Manual

OMICRON 65
Technical specifications
3.8 MPC1 measurement protection case
3.8.1 Mechanical data
3.8.2 Environmental conditions
3.8.3 Standards
Table 3-25: Mechanical data
Parameter Value
Dimensions (W × H × D) 477 mm × 174 mm × 330 mm
(18.80 inch × 6.85 inch × 13.00 inch)
Weight (empty) 3900 g
Table 3-26: Environmental conditions
Parameter Value
Humidity 5 % … 95 %, non-condensing
Ambient temperature (operating MPD 800 system)
Option A, B and C
Option D and E
-20 °C … +45 °C
-20 °C … +50 °C
Ambient temperature (storage for the MPD 800 system) -20 °C … +30 °C
Ambient temperature (charging RBP1) 0 °C … +40 °C
Maximum operating altitude 4000 m
Maximum storage altitude 12000 m
Table 3-27: Standards
Parameter Standard Value
Ingress protection
(connectors mated)
IEC/EN 60529 IP44
