3.5 MCU2 multi-device control unit
3.5.1 Device data
3.5.2 Power data
Table 3-12: Device data
Parameter Value
Wavelength FO 1 1308 nm
Wavelength FO 2 (if present) 1308 nm
Wavelength FO 3 (if present) 820 nm (MPD 600 version)
1308 nm (MPD 800 version)
Wavelength TRIGGER 430 nm … 1100 nm
Maximum fiber-optic cable length and type FO 1, FO 2, FO 3 2.5 km, 50/150 µm OM3
Maximum fiber-optic cable length and type FO1, FO2 for
MCU2 special single mode version
≤ 20 km, 9/125 µm
Connector types on the rear panel 2 x LC (duplex) and 1 x ST (duplex)
GPS antenna connector type on the front panel SMA,
Other GPS antennas can also be
used. Since these have not been
tested in combination with the
MCU2, OMICRON cannot guarantee
that third-party components will work
as desired.
Type of GPS antenna GPS/GLONASS antenna
1.574 GHz … 1.606 GHz, 28 dB gain
Manufacturer: Tallysman Wireless
Type of GPS cable H155 PE; 20 m (recommended)
Connector: both sides SMA
Table 3-13: Power data
Parameter Value
Power supply 5 V ±5 % according to USB 3.0
specification
Power consumption ≤ 4.5 W
