MPD 800 User Manual
56 OMICRON
3.3.4 Mechanical data
3.3.5 Environmental conditions
3.3.6 Standards
Table 3-4: Mechanical data
Parameter Value
Dimensions (W × D × H) 119 mm × 190 mm × 55 mm
(4.69inch×7.48inch×2.17inch)
Weight 870 g
Table 3-5: Environmental conditions
Parameter Value
Humidity 5 % … 95 %, non-condensing
Operating time at -20°C / 23°C / 55°C (using one RBP1) 13 hours / 16 hours / 16 hours
Ambient temperature (operating) -20 °C … +55 °C
Ambient temperature (storage) -40 °C … +85 °C
Maximum operating altitude 4000 m
Maximum storage altitude 12000 m
Ambient temperature OMICRON 24 W DC supply +10 °C … +55 °C
Table 3-6: Standards
Parameter Standard Value
EMC IEC/EN 61326-1 (industrial
electromagnetic environment)
FCC subpart B of part 15, class A
Safety IEC/EN/UL 61010-1
IEC/EN/UL 61010-2-030
Laser class EN 60825-1:2007
EN 60825-2:2007
Eye-safe laser class 1
Ingress protection
(connectors mated)
IEC/EN 60529 IP4x
Partial discharge
measurement
IEC 60270
