Omicron MPD 800 User Manual

MPD 800 User Manual
58 OMICRON
3.4.3 Mechanical data
3.4.4 Environmental conditions
Output partial discharge impulse voltage PD output (max.) 80 V
peak
Input surge current withstand capability
≤8kA (≤500A
2
s)
Maximum voltage between RTN/OUT connector and GND
connector (applies to CPL2 only)
3
140 V
RMS
1. Relative to 1 MHz
2. In order to be more than 60 dB above the internal noise, the measuring current should be at least 5 µA
RMS
.
3. The voltage drop across the input impedance of the equipment connected to OUT/RTN should not exceed 140 V
RMS
with the
maximum input current applied.
Table 3-9: Mechanical data
Parameter Value
Dimensions (W × D × H) 119 mm × 175 mm × 55 mm
(4.69inch×6.89inch×2.17inch)
Weight 1270 g
Table 3-10: Environmental conditions
Parameter Value
Humidity 5 % … 95 %, non-condensing
Ambient temperature (operating) -20 °C … +55 °C
Ambient temperature (storage) -40 °C … +85 °C
Maximum operating altitude 4000 m
Maximum storage altitude 12000 m
Table 3-8: Device data (continued)
Parameter Value
