MPD 800 User Manual
64 OMICRON
3.7 V-to-AC-adapter 100kOhm
3.7.1 Device data
3.7.2 Mechanical data
3.7.3 Environmental conditions
Table 3-22: Device data
Parameter Value
Nominal resistance 100 kΩ
Initial resistance accuracy ±0.02 %
Typical temperature coefficient 2 ppm/K
Maximum power dissipation 200 mW
Maximum working voltage 200 V
peak
/ 140 V
RMS
continuous
Maximum withstand voltage (open circuit) 300 V
peak
(overvoltage CAT I)
Long term resistance deviation (1000 full load cycles / 2 years)<±0.15%
Table 3-23: Mechanical data
Parameter Value
Dimensions (W × Ø) 72 mm × 24 mm
(2.83inch×0.94inch)
Weight 55 g
Table 3-24: Environmental conditions
Parameter Value
Humidity 5 % … 95 %, non-condensing
Ambient temperature (operating) -20 °C … +55 °C
Ambient temperature (storage) -40 °C … +85 °C
Maximum operating altitude 4000 m
Maximum storage altitude 12000 m
