Voltage range PD input (max. peak) 80 V, 40 V, 20 V, 10 V, 5 V, 2.5 V,
1.28 V, 640 mV, 320 mV, 160 mV,
80 mV, 40 mV, 20 mV, 10 mV
Input partial discharge impulse voltage PD input (max. 100µs) 80 V
peak
PD input current (max. RMS continuous) 100 mA (0.5 W at 50 Ω)
PD input current internal CPL (max. RMS continuous)
3)
150 mA
Input current AC input (max. RMS continuous) 150 mA
RMS
Input current AC input (max. peak) 400 mA
peak
Current range AC input (max. peak) 400 mA, 200 mA, 20 mA, 2 mA,
200 µA
Input current AC input (min. RMS)
4)
20 nA
RMS
PD input (min. RMS continuous for sync)
5)
2µA
DC measurement:
AC input (min. DC current)
6
AC input (max. DC current)
100 nA
200 mA
VLF measurement:
PD input (min. RMS)
7)
PD input (max. RMS continuous)
500 nA
200 mA
Input surge current withstand capability PD input
(internal quadripole enabled)
≤4.5kA (≤30A
2
s)
Input surge current withstand capability PD input
(8/20 µs, 10 operation)
≤4.5kA (≤30A
2
s, <1 ms)
Input current withstand capability PD input
(1 s, 50 Hz, 10 operations)
(internal quadripole enabled)
20 A
Input current withstand capability AC input (100 s, 50 Hz) 5 A
Time domain integration 56 ns … 8 µs
Sampling rate PD input 125 MS/s
Sampling rate AC input 31.25 kS/s
Resolution PD input 14 Bits
Resolution AC input 24 Bits
PD pulse rate (max.) 2 Mio./s
PD input low-pass filters 1.1 MHz, 2.3 MHz, 4.7 MHz
PRPD pre-recording time 0 s … 30 s
PD scope recording depth 131 µs
Table 3-2: Device data (continued)
Parameter Value

Omicron MPD 800 Specifications

General

Brand	Omicron
Model	MPD 800
Category	Test Equipment
Language	English
