5 - 15
5 DriveProgramming User Variables
DriveProgramming User’s Manual (I622-E1)
5-5 Inverter Monitor Variables
5
Use this function to monitor the output torque. The monitored data is equivalent to the data of the Out-
put Torque Monitor (dA-17). This variable is read-only.
Use this function to monitor the output voltage. The monitored data is equivalent to the data of the Out-
put Voltage Monitor (dA-18). This variable is read-only.
Use this function to monitor the input power. The monitored data is equivalent to the data of the Input
Power Monitor (dA-30). This variable is read-only.
Use this function to monitor the total operation time. The monitored data is equivalent to the data of the
Total RUN Time Monitor (dC-22). This variable is read-only.
Use this function to monitor the total power ON time. The monitored data is equivalent to the data of the
Cumulative power-on time (dC-24). This variable is read-only.
The DriveProgramming's user monitor variables UMon(0) to UMon(4) are the signed 2-word variables.
If any data is set in the user monitor variables UMon(0) to UMon(4) in the DriveProgramming program,
the data can be displayed through the inverter's user monitor parameters (db-08, db-10, db-12, db-14,
db-16). Use this function to externally display the calculation status of the program.
Function
variable
Description Data range
Default
data
Unit Data size R/W
Tmon Output Torque Monitor
(dA-17)
−10,000 to 10,000 − % Signed
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
Vout Output Voltage Monitor
(dA-18)
0 to 8,000 − 0.1 V Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
Power Input Power Monitor
(dA-30)
0 to 60,000
(132 kW or less)
0 to 20,000
(160 kW or more)
− 0.1 kW Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
RUN-Time Total RUN Time Monitor
(dC-22)
0 to 1,000,000 − Time Unsigned
2 words
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
ON-Time Cumulative power-on time
(dC-24)
0 to 1,000,000 − Time Unsigned
2 words
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
PlsCnt Pulse counter monitor
(dA-28)
0 to 2,147,483,647 −−Signed
2 words
R
