5 DriveProgramming User Variables
5 - 16
DriveProgramming User’s Manual (I622-E1)
Use this function to monitor the current position. The monitored data is equivalent to the data of the
Current Position Monitor (dA-20).
Use this function to monitor the inverter's total number of faults. The monitored data is equivalent to the
data of the Fault Counter. This variable is read-only.
Use this function to monitor the data of the last six trips of the inverter. The monitored data is equivalent
to the data of the Fault Monitor 1 to 10. This variable is read-only. Contents about trip are figures (***) in
trip factor (E***) displayed on Trip History of LCD operator.
The last 10 retry factors for an inverter can be monitored. The details about the monitor correspond to
retry monitor 1 to 10 factor. This variable can be only read.
The contents are figures (***) in retry factor (r***) displayed on Retry History of LCD operator.
Use this function to monitor the inverter's internal DC voltage. The monitored data is equivalent to the
data of the DC Voltage Monitor (dA-40). This variable is read-only.
Function
variable
Description Data range
Default
data
Unit Data size R/W
POS Current Position Monitor
(dA-20)
In the case of
AA121=10 and
AA123=03, data
range -2147483648
to 2147483647.
In the case of the
condition men-
tioned above, data
range -536870912
to 536870911
−−Signed
2 words
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
ERR-CNT Fault Counter 0 to 65,535 − Times Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
ERR(1) to
ERR(10)
Fault Monitor 1 to 10 0 to 255 −−Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
RETRY(1)
to (10)
Retry monitor 1 to 10 fac-
tor
0 to 255 −−Unsigned
1 word
R
Function
variable
Description Data range
Default
data
Unit Data size R/W
DCV DC Voltage Monitor
(dA-40)
0 to 10,000 − 0.1 V Unsigned
1 word
R
