4-7
4 Data Exchange with the CPU Unit
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
4-1 Data Exchange with the CPU Unit
4
4-1-2 Accessing From the User Program
Allocate the I/O data to the user-defined variables as shown in the example below.
Additional Information
For details on CJ Unit memory, variable allocation and user-defined variable registration, refer to
section 5-5-3 Assigning User-defined Variables and Sysmac Studio (Ver. 1.0) Operation Manual
(Cat. No. W504).
Words
allocated
I/O data
CIO 3200 Output Allocation for slave data (station address 0)
CIO 3300 Input Allocation for slave data (station address 0)
CIO 3301 Input Allocation for slave data (station address 0)
