3 Configuration Software
3-2
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
3-1 CX-ConfiguratorFDT
Select Program, OMRON, and CX-ConfiguratorFDT from the Start Menu if the default program folder
name is used. The first time CX-ConfiguratorFDT is started, the Device Catalog will still be empty.
Therefore, the following dialog will be displayed on top of the CX-ConfiguratorFDT application window.
Select Yes to generate the Device Catalogue for the first time. This action may take several minutes
depending on the number of installed DTMs.
After updating the Device Catalogue, it will open in the CX-ConfiguratorFDT application window.
3-1-1 Starting CX-ConfiguratorFDT
3-1-2 CX-ConfiguratorFDT Main Window
Network view Device Catalogue
DTM view
Status Bar
Tool Bar
