5-11
5 Operation
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
5-2 Setting Up a Network
5
5-2-2 Changing Device and DTM Addresses
The window shown below will be displayed.
In order to change the slave DTM address perform the following steps.
1
Select the slave device in the list.
2
Enter the new address in the field Address in the lower right corner of the window.
Press the Set button. The Status field will display the status of this service
After changing the slave DTM address, the new address will also be shown in the Network view.
