1 Features and System Configuration
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
1-3 CX-ConfiguratorFDT
1
1-3-2 Specifications
Note Note For more information on the GRT1-PRT DTM, refer to the SmartSlice GRT1- series GRT1-PRT PROFI-
BUS Communication Unit Operation Manual (Cat. No. W04E-EN-□).
CJ1W-
PRM21 DTM
Device setup Device setup allows the user to:
• Select the PROFIBUS Master Unit’s unit number.
• Configure the communication link between the PC and the Unit.
This function invokes the user interface of CX-Server.
• Test the Units communication link and read out the Unit’s informa-
tion.
Master setup It allows enabling of Auto Addressing to facilitate I/O data mapping,
as well as defining the Unit’s behavior in case of
• a network malfunction.
• CPU mode changes between PROGRAM and RUN mode.
Bus parameter setup The bus parameter setup allows the selection of baud rate and cal-
culation and editing of specific bus parameters.
Slave area setup The Slave area setup allows the user to define the I/O Data map-
ping of the I/O Data from each of the slave devices on to CPU
memory areas.
Monitoring functions • Master status read out.
• Slave status and slave diagnostics read-out.
• Read out of the Unit’s error log.
Additional Master functions • Set remote slave address.
• Communication channels for PROFIBUS DP-V1 MSAC1 mes-
sages.
• Communication channels for PROFIBUS DP-V1 MSAC2 mes-
sages.
These functions are implemented as of Unit version 3.0.
Support functions • Context sensitive help functions.
• Multi-language support.
Generic
Slave DTM
Support functions • Context sensitive help functions.
• Multi-language support.
I/O configuration setup The I/O configuration setup function allows:
• Selection of device address.
• Enable/disable watchdog.
• Overview of available I/O modules.
• Selection of I/O modules, including Addition, Insertion and
Removal of multiple modules.
Parameter setup The Parameter setup function:
• Setting of common as well as module dependent parameters.
• Setting of PROFIBUS DP Extension parameters.
• Setting of PROFIBUS DP-V1 dependent parameters.
Group setting The Group setup function allows definition of the group to which the
associated slave device will belong.
Monitoring functions The Monitoring functions provides a display of
• Standard Slave diagnostics flags.
• Extended diagnostics messages.
Support functions • Context sensitive help functions.
• Multi-language support.
