Omron CJ Series User Manual

3 Configuration Software
3-4
CJ-series PROFIBUS Master Unit Operation Manual for NJ-series CPU Unit (W509)
 Main Menu
The main menu of CX-ConfiguratorFDT provides all the necessary functionality to handle a com-
plete project. The table below lists the main menu and their sub menu items.
Menu Command Short Key Description
File New CTRL-N Creates a new Project.
Open CTRL-O Opens an existing Project.
Save CTRL-S Saves the displayed Project to a file.
Save As... --- Save as is the same as Save, but the Filename Specification
Window is always displayed.
Export Project to HTML --- Exports Project data in HTML format and launches the
browser.
Project Properties... --- Opens an edit window to add or edit Project information.
Recently used File List --- Lists the recently used Project files.
Exit --- Exits CX-ConfiguratorFDT.
Edit Cut CTRL-X Cuts devices and pastes them to the clipboard
Copy CTRL-C Copies devices to the clipboard.
Paste CTRL-V Copies devices from the clipboard to the cursor position.
View Network view --- Hides or un-hides the Network view.
Device Catalogue --- Opens or closes the Device Catalogue.
Tool Bar --- Hides or un-hides the Tool Bar.
Status Bar --- Hides or un-hides the Status Bar.
Error Logging --- Hides or un-hides the Error Logging window.
FDT Monitoring --- Hides or un-hides the FDT Monitoring view.
Device Add Device... --- Opens up the Device Catalog Add window, from which
devices can be added to the selected network tree.
Upload Parameters --- Uploads the parameters from a device to its associated DTM.
Download Parameters --- Downloads the parameters from DTM to its associated device.
Export to HTML --- Exports the properties and parameters of the selected DTM,
or the network to a HTML file and opens the default browser.
Properties --- Displays the properties of the selected DTM, or the network.
Tools User Management... --- Displays the user management (i.e password management)
window.
Window Cascade --- Cascades all open DTM User Interfaces.
Tile Horizontally --- Tiles all open DTM User Interfaces horizontally.
Tile Vertically --- Tiles all open DTM User Interfaces vertically.
Close All --- Closes all open DTM User Interfaces.
Help Contents --- Opens the Help dialog and lists the Help file contents.
Index --- Opens the Help dialog and lists the Help Index.
About CX-ConfiguratorFDT.... --- Opens the About dialog window for CX-ConfiguratorFDT.
