103
PULSE OUTPUT: PLS2(887) Section 5-7
Ladder Symbol
Variations
Applicable Program Areas
Operands P: Port Specifier
The port specifier indicates the port.
M: Output Mode
The content of M specifies the parameters for the pulse output as follows:
PLS2(887)
P
M
S
F
P: Port specifier
M: Output mode
S: First word of settings table
F: First word of starting frequency
Variations Executed Each Cycle for ON Condition PLS2(887)
Executed Once for Upward Differentiation @PLS2(887)
Executed Once for Downward Differentiation Not supported
Immediate Refreshing Specification Not supported
Block program areas Step program areas Subroutines Interrupt tasks
OK OK OK OK
PPort
0000 hex Pulse output 0
0001 hex Pulse output 1
03478
111215
M
Mode
0 hex: Relative pulses
1 hex: Absolute pulses
Direction
0 hex: CW
1 hex: CCW
Pulse output method (See note.)
0 hex: CW/CCW
1 hex: Pulse + direction
Always 0 hex.
Note: Use the same pulse output method when using both pulse outputs 0 and 1.
