CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from
User Program
The device variables for CJ-series Units that correspond to bits 0 to 15 of 4 words from CIO n+6 to
n+9 are as follows:
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+8 0 *_CnctNdCmd[32] Disconnect/Connect Switch for Node
Address 32 Slave
1 *_CnctNdCmd[33] Disconnect/Connect Switch for Node
Address 33 Slave
2 *_CnctNdCmd[34] Disconnect/Connect Switch for Node
Address 34 Slave
3 *_CnctNdCmd[35] Disconnect/Connect Switch for Node
Address 35 Slave
4 *_CnctNdCmd[36] Disconnect/Connect Switch for Node
Address 36 Slave
5 *_CnctNdCmd[37] Disconnect/Connect Switch for Node
Address 37 Slave
6 *_CnctNdCmd[38] Disconnect/Connect Switch for Node
Address 38 Slave
7 *_CnctNdCmd[39] Disconnect/Connect Switch for Node
Address 39 Slave
8 *_CnctNdCmd[40] Disconnect/Connect Switch for Node
Address 40 Slave
9 *_CnctNdCmd[41] Disconnect/Connect Switch for Node
Address 41 Slave
10 *_CnctNdCmd[42] Disconnect/Connect Switch for Node
Address 42 Slave
11 *_CnctNdCmd[43] Disconnect/Connect Switch for Node
Address 43 Slave
12 *_CnctNdCmd[44] Disconnect/Connect Switch for Node
Address 44 Slave
13 *_CnctNdCmd[45] Disconnect/Connect Switch for Node
Address 45 Slave
14 *_CnctNdCmd[46] Disconnect/Connect Switch for Node
Address 46 Slave
15 *_CnctNdCmd[47] Disconnect/Connect Switch for Node
Address 47 Slave
