z CIO n+10 (Unit Status 1)
The device variables for CJ-series Unit that corresponds to all bits of a word starting with CIO n+10
is as follows:
CIO n+9 0 *_CnctNdCmd[48] Disconnect/Connect Switch for Node
Address 48 Slave
1 *_CnctNdCmd[49] Disconnect/Connect Switch for Node
Address 49 Slave
2 *_CnctNdCmd[50] Disconnect/Connect Switch for Node
Address 50 Slave
3 *_CnctNdCmd[51] Disconnect/Connect Switch for Node
Address 51 Slave
4 *_CnctNdCmd[52] Disconnect/Connect Switch for Node
Address 52 Slave
5 *_CnctNdCmd[53] Disconnect/Connect Switch for Node
Address 53 Slave
6 *_CnctNdCmd[54] Disconnect/Connect Switch for Node
Address 54 Slave
7 *_CnctNdCmd[55] Disconnect/Connect Switch for Node
Address 55 Slave
8 *_CnctNdCmd[56] Disconnect/Connect Switch for Node
Address 56 Slave
9 *_CnctNdCmd[57] Disconnect/Connect Switch for Node
Address 57 Slave
10 *_CnctNdCmd[58] Disconnect/Connect Switch for Node
Address 58 Slave
11 *_CnctNdCmd[59] Disconnect/Connect Switch for Node
Address 59 Slave
12 *_CnctNdCmd[60] Disconnect/Connect Switch for Node
Address 60 Slave
13 *_CnctNdCmd[61] Disconnect/Connect Switch for Node
Address 61 Slave
14 *_CnctNdCmd[62] Disconnect/Connect Switch for Node
Address 62 Slave
15 *_CnctNdCmd[63] Disconnect/Connect Switch for Node
Address 63 Slave
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+10 0 to 15 *_Unit1Sta Unit Status 1 (The functions of bits 0 to 15
of CIO n+10 correspond to those of bits 0
to 15 of this CJ-series Unit device vari-
able.)
