Appendices
A-32
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
The device variables for CJ-series Units that correspond to bits 0 to 7 and 8 to 15 of each word are
as follows:
D m+61 0 to 7 *_Nd36Sta Detailed Slave Status Table for Node Address
36
8 to 15 *_Nd37Sta Detailed Slave Status Table for Node Address
37
D m+62 0 to 7 *_Nd38Sta Detailed Slave Status Table for Node Address
38
8 to 15 *_Nd39Sta Detailed Slave Status Table for Node Address
39
D m+63 0 to 7 *_Nd40Sta Detailed Slave Status Table for Node Address
40
8 to 15 *_Nd41Sta Detailed Slave Status Table for Node Address
41
D m+64 0 to 7 *_Nd42Sta Detailed Slave Status Table for Node Address
42
8 to 15 *_Nd43Sta Detailed Slave Status Table for Node Address
43
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+65 0 to 7 *_Nd44Sta Detailed Slave Status Table for Node Address
44
8 to 15 *_Nd45Sta Detailed Slave Status Table for Node Address
45
D m+66 0 to 7 *_Nd46Sta Detailed Slave Status Table for Node Address
46
8 to 15 *_Nd47Sta Detailed Slave Status Table for Node Address
47
D m+67 0 to 7 *_Nd48Sta Detailed Slave Status Table for Node Address
48
8 to 15 *_Nd49Sta Detailed Slave Status Table for Node Address
49
D m+68 0 to 7 *_Nd50Sta Detailed Slave Status Table for Node Address
50
8 to 15 *_Nd51Sta Detailed Slave Status Table for Node Address
51
D m+69 0 to 7 *_Nd52Sta Detailed Slave Status Table for Node Address
52
8 to 15 *_Nd53Sta Detailed Slave Status Table for Node Address
53
D m+70 0 to 7 *_Nd54Sta Detailed Slave Status Table for Node Address
54
8 to 15 *_Nd55Sta Detailed Slave Status Table for Node Address
55
D m+71 0 to 7 *_Nd56Sta Detailed Slave Status Table for Node Address
56
8 to 15 *_Nd57Sta Detailed Slave Status Table for Node Address
57
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
