A-33
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from User Program
The device variables for CJ-series Units that correspond to bits 0 to 15 of each word are as follows:
D m+72 0 to 7 *_Nd58Sta Detailed Slave Status Table for Node Address
58
8 to 15 *_Nd59Sta Detailed Slave Status Table for Node Address
59
D m+73 0 to 7 *_Nd60Sta Detailed Slave Status Table for Node Address
60
8 to 15 *_Nd61Sta Detailed Slave Status Table for Node Address
61
D m+74 0 to 7 *_Nd62Sta Detailed Slave Status Table for Node Address
62
8 to 15 *_Nd63Sta Detailed Slave Status Table for Node Address
63
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+43, m+44
to m+74
0 of each word *_Nd0Err,
*_Nd2Err,
to
*_Nd62Err
Slave Error for node address 0, 2 to 62
1 of each word *_Nd0VefyErr,
*_Nd2VefyErr,
to
*_Nd62VefyErr
Slave Verification Error for node address 0, 2 to
62
2 of each word *_Nd0CfgErr,
*_Nd2CfgErr,
to
*_Nd62CfgErr
Slave Configuration Error for node address 0, 2
to 62
3 of each word *_Nd0IOErr,
*_Nd2IOErr,
to
*_Nd62IOErr
Slave Remote I/O Communications Error for
node address 0, 2 to 62
4 of each word Reserved by system
5 of each word *_Nd0COSSendErr,
*_Nd2COSSendErr,
to
*_Nd62COSSendErr
Master COS Send Error for node address 0, 2 to
62
6 of each word *_Nd0SListRegSta,
*_Nd2SListRegSta,
to
*_Nd62SListRegSta
Scan List Registration Flag for node address
0, 2 to 62
7 of each word *_Nd0IOCommSta,
*_Nd2IOCommSta,
to
*_Nd62IOCommSta
Remote I/O Communications Flag at node
address 0, 2 to 62
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
