Appendices
A-44
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
z Identity Object (01 Hex)
Master Unit Device Profile
General data Compatible DeviceNet Specifications Volume I - Release 2.0
Volume II - Release 2.0
Vendor name OMRON Corporation Vendor ID = 47
Device profile name Communication Adapter Profile number = 12
Manufacturer revision 1.1
Physical conform-
ance data
Network current consumption 24 VDC, 30 mA max.
Connector type Open plug
Physical insulation Yes
Supported indicators Module, Network
MAC ID setting Rotary switch
Default MAC ID 63
Baud rate setting DIP switch
Supported baud rates 125 kbit/s, 250 kbit/s, and 500 kbit/s
Communications
data
Predefined Master/Slave connection set Group 2 client
Group 2 only client
Group 2 server
Dynamic connection support (UCMM) Yes
Explicit message fragmentation support Yes
Object Mounting
Object class Attribute Not supported
Service Not supported
Item ID content
Get
(read)
Set
(write)
Value
Object instance Attribute 1 Vendor Yes No 47
2 Product type Yes No 12
3 Product code Yes No CJ1W-DRT21: 05
4 Revision Yes No 1.1
5 Status (bits supported) Yes No ---
6 Serial number Yes No Unique for each Unit
7 Product name Yes No CJ1W-DRM21
8 State NoNo---
Service DeviceNet Service Parameter option
05 Reset None
0E Get Attribute Single None
