A-45
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-4 Multi-vendor Applications
App
z Message Router Object (02 Hex)
z DeviceNet Object (03 Hex)
z Connection Object (05 Hex)
Object class Attribute Not supported
Service Not supported
Object instance Attribute Not supported
Service Not supported
Vendor specification addition No
Item ID content
Get
(read)
Set
(write)
Value
Object class Attribute 1 Revision Yes No 2
Service DeviceNet service Parameter option
0E Get_Attribute_Single No
Item ID content
Get
(read)
Set
(write)
Value
Object instance Attribute 1 MAC ID Yes No ---
2 Baud rate Yes No ---
3 BOI Yes No 0
4 Bus–off counter Yes No 0
5 Allocation information Yes No ---
6 MAC ID switch
changed
No No ---
7 Baud rate switch
changed
No No ---
8 MAC ID switch value No No ---
9 Baud rate switch value No No ---
Service DeviceNet service Parameter option
0E Get_Attribute_Single No
4B Allocate_Master/
Slave_Connection Set
No
4C Release_Master/
Slave_Connection Set
No
Object class Attribute Not supported
Service Not supported
Max. number of instances 203
