Appendices
A-46
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
Object instance
1
Section Information
Max. No. of
instances
Instance
type
Explicit Message 1
Produc-
tion trig-
ger
Cyclic ---
Trans-
port type
Server
Trans-
port class
3
Attribute
ID content
Get
(read)
Set
(write)
Value
1 State Yes No ---
2 Instance_type Yes No 0
3 Transport_class_trigger Yes No 83 hex
4 Produced_connection_ID Yes No ---
5 Consumed_connection_ID Yes No ---
6 Initial_comm_characteristics Yes No 21 hex
7 Produced_connection_size Yes No 553
8 Consumed_connection_size Yes No Format 16-16: 557
Format 8-8: 555
Format 16-8, 8-16:
556
9 Expected_packed_rate Yes Yes ---
12 Watchdog_timeout_action Yes Yes 1 or 3
13 Produced_connection_path_
length
Ye s N o 0
14 Produced_connection_path Yes No empty
15 Consumed_connection_path_
length
Ye s N o 0
16 Consumed_connection_path Yes No empty
17 Production_inhibit_time Yes Yes ---
Service DeviceNet service Parameter option
05 Reset No
0E Get_Attribute_Single No
10 Set_Attribute_Single No
