Appendices
A-48
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
* Number of input bytes used by Slave.
Object instance
3
Section Information
Max. No. of
instances
Instance
type
Bit Strobed I/O 1
Produc-
tion trig-
ger
Cyclic ---
Trans-
port type
Server
Trans-
port class
2
Attribute
ID content
Get
(read)
Set
(write)
Value
1 State Yes No ---
2 Instance_type Yes No 1
3 Transport_class_trigger Yes No 82 hex
4 Produced_connection_ID Yes No ---
5 Consumed_connection_ID Yes No ---
6 Initial_comm_characteristics Yes No 2
7 Produced_connection_size Yes No *
8 Consumed_connection_size Yes No 8
9 Expected_packed_rate Yes Yes ---
12 Watchdog_timeout_action Yes No 0
13 Produced_connection_path_
length
Ye s N o 0
14 Produced_connection_path Yes No empty
15 Consumed_connection_path_
length
Ye s N o 4
16 Consumed_connection_path Yes No 20 94 24 01 hex
17 Production_inhibit_time Yes Yes ---
Service DeviceNet service Parameter option
05 Reset No
0E Get_Attribute_Single No
10 Set_Attribute_Single No
To Next Page
