A-49
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-4 Multi-vendor Applications
App
* Number of input bytes used by Slave.
Object instance
4
Section Information
Max. No. of
instances
Instance
type
COS/cyclic I/O 1
Produc-
tion trig-
ger
Cyclic ---
Trans-
port type
Client
Trans-
port class
0 (no ACK)/2 (with ACK)
Attribute
ID content
Get
(read)
Set
(write)
Value
1 State Yes No ---
2 Instance_type Yes No *
3 Transport_class_trigger Yes No 02 hex (with Cyclic
ACK)
12 hex (with COS
ACK)
00 hex (no Cyclic
ACK)
10 hex (no COS
ACK)
4 Produced_connection_ID Yes No ---
5 Consumed_connection_ID Yes No FFFF hex (no
ACK)
6 Initial_comm_characteristics Yes No 01 hex (with ACK)
0F hex (no ACK)
7 Produced_connection_size Yes No *
8 Consumed_connection_size Yes No ---
9 Expected_packed_rate Yes Yes ---
12 Watchdog_timeout_action Yes No 0
13 Produced_connection_path_
length
Ye s N o 4
14 Produced_connection_path Yes No 20 94 24 01 hex
15 Consumed_connection_path_
length
Ye s N o 0 ( n o AC K )
4 (with ACK)
16 Consumed_connection_path Yes No empty (no ACK)
20 2B 24 01 (with
ACK)
17 Production_inhibit_time Yes Yes ---
Service DeviceNet service Parameter option
05 Reset No
0E Get_Attribute_Single No
10 Set_Attribute_Single No
