A-51
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-4 Multi-vendor Applications
App
z PLC Object (2F Hex)
Bit-strobe client 22 hex
Explicit client 23 hex
Explicit server 83 hex
Object class Attribute Not supported
Service Not supported
DeviceNet service Parameter option
Object
instance
1 (CIO
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
3 (DM
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
4 (WR
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
5 (HR
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
6 (AR
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
7 (TIM/
CNT
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Object
instance
8-20
(EM0 to
EMC
area)
Service 1C Block String Read Logical Area Address Length
1D Block StringN Read Logical Area Address Length
1E Block String Write Logical Area Address
1F Block StringN Write Logical Area Address
Format Transport_class_trigger
