Appendices
A-52
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
Note The refresh area types are shown in the following table.
PLC area Refresh area type Refresh address
CIO 1 CIO 0000 to CIO 6143
DM 3 D00000 to D32767
WR 4 W000 to W511
HE 5 H000 to H511
EM (bank 0) 8 E0_00000 to E0_32767
EM (bank 1) 9 E1_00000 to E1_32767
EM (bank 2) A E2_00000 to E2_32767
EM (bank 3) B E3_00000 to E3_32767
EM (bank 4) C E4_00000 to E4_32767
EM (bank 5) D E5_00000 to E5_32767
EM (bank 6) E E6_00000 to E6_32767
EM (bank 7) F E7_00000 to E7_32767
EM (bank 8) 10 E8_00000 to E8_32767
EM (bank 9) 11 E9_00000 to E9_32767
EM (bank 10) 12 EA_00000 to EA_32767
EM (bank 11) 13 EB_00000 to EB_32767
EM (bank 12) 14 EC_00000 to EC_32767
To Next Page
