10. Appendix 2 Setting the Tag Data Links Using the Software
53
10.3.3. Exporting the Global Variables
Export the global variables in a CSV file to use as tags in the Network Configurator.
1
Double-click Global Variables
under Programming - Data in
the Multiview Explorer.
2
The Global Variables Tab Page
is displayed in the Edit Pane.
Right-click on the pane and
Select Select All.
All the selected variables are
highlighted.
3
Select Export Global Variables
- Network Configurator from
the Tools Menu.
4
The Save As Dialog Box is
displayed. Enter EIP002 in the
File name Field.
Click the Save Button.

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
