10. Appendix 2 Setting the Tag Data Links Using the Software
54
10.3.4. Connecting Online and Transferring the Project Data
Connect online with the Sysmac Studio and transfer the project data to the Controller.
Always confirm safety at the destination node before you transfer a user
program, configuration data, setup data, device variables, or values in memory
used for CJ-series Units from the Sysmac Studio.
The devices or machines may perform unexpected operation regardless of the
operating mode of the CPU Unit.
1
Select Check All Programs
from the Project Menu.
2
The Build Tab Page is displayed
in the Edit Pane.
Confirm that "0 Errors" and "0
Warnings" are displayed.
3
Select Rebuild Controller from
the Project Menu.
4
A confirmation dialog box is
displayed. Check the contents
and click the Yes Button.
5
Confirm that "0 Errors" and "0
Warnings" are displayed in the
Build Tab Page.
6
Select Communications Setup
from the Controller Menu.
