Omron CJ2 Series User Manual

10. Appendix 2 Setting the Tag Data Links Using the Software
62
10
The device parameters are
uploaded. When uploading is
completed, the dialog box on the
right is displayed.
Check the contents and click the
OK Button.
11
After uploading is completed,
confirm that the Network
Configuration Pane shows the
updated IP addresses of the
devices.
IP address of node 1:
192.168.250.1
IP address of node 2:
192.168.250.2

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
