10. Appendix 2 Setting the Tag Data Links Using the Software
70
4
The Import Connection
Configuration Dialog Box is
displayed. Select EIP002.csv
and click the Open Button.
*In the Look in Field, specify the
folder in which the file was
saved in Section 10.3.3
Exporting the Global Variables.
5
The right dialog boxes may not
be displayed depending on the
status of the Controller and
software used. In such a case,
proceed to the next step.
The right dialog box is
displayed. Confirm that there is
no problem and click the Yes
Button.
The right dialog box is
displayed. Confirm that there is
no problem and click the No
Button.
Make sure that tag sets are not
created automatically.
6
The Edit Tags Dialog Box is
displayed again.
Click the Tag Sets Tab.
