10. Appendix 2 Setting the Tag Data Links Using the Software
73
11
The Edit Tag Set Dialog Box is
displayed.
Select EIP002_D10000_IN from
the Candidate Tag List and click
the << Button.
12
EIP002_D10000_IN moves to
the Tag List.
Move all variables from the
Candidate Tag List to the Tag
List in the same way.
13
Enter EIP002_IN in the Name
Field.
Click the Regist Button.
14
The Edit Device Parameters
Dialog Box is displayed. Click
the Close Button.
15
The Edit Device Parameters
Dialog Box is displayed.
EIP002_IN and 20Byte are
displayed.

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
