10. Appendix 2 Setting the Tag Data Links Using the Software
79
13
The Edit Connection Dialog Box
is displayed again. Click the
Close Button.
14
The Edit Device Parameters
Dialog Box is displayed again.
Click the OK Button.
15
When the connection is
completely allocated, the
registration destination node
address is displayed under the
device icon of the destination
device on the Network
Configuration Pane.
