165
Logic Operations Section 4-25
11. Changing Event Input Data
Select the event input conditions from the following setting ranges.
Note The event input data can be changed from the default setting even
if there is no event input terminal (external input). By changing the
default setting, the event input assignment parameters will be dis-
played at the Controller display and can be set from the Controller.
12. Changing the Event Input Assignment Function
Select the setting for the event input assignment.
When a work bit is selected as event input data, Communications Write
Enable/Disable cannot be assigned to an event input.
13. Changing Control Output and Auxiliary Output Settings
Control output and auxiliary output assignments can be changed. The
items that can be changed depend on the Controller model. For details, re-
fer to 3-5-3 Assigned Output Functions.
Assigning a work bit to either a control output or to an auxiliary output is
also considered to be the same as assigning an alarm. For example, if
work bit 1 is set for the Auxiliary Output 1 Assignment parameter, then
alarms 1 to 3 have been assigned.
14. Displaying Parameter Guides
A description of the parameters can be displayed.
15. Displaying the Work Bit Use Destinations
Display a list of destinations where the work bits are used.
Operating Procedure This procedure uses event input 2 to change to RUN or STOP.
Event input 2 ON: RUN
Event input 2 OFF: STOP
Parameter name Setting range
Event Input Data 1 0: Not assigned.
1: Event input 1 (external input)
2: Event input 2 (external input)
3: Event input 3 (external input)
4: Event input 4 (external input)
5: Work bit 1
6: Work bit 2
7: Work bit 3
8: Work bit 4
9: Work bit 5
10: Work bit 6
11: Work bit 7
12: Work bit 8
Event Input Data 2 Same as for event input data 1
Event Input Data 3 Same as for event input data 1
Event Input Data 4 Same as for event input data 1
