Omron E5AN-H User Manual

236
Initial Setting Level Section 5-9
• This parameter sets the upper and lower limit values of transfer outputs.
Note (1) If the set point is selected, the remote SP will be output as long as the
Remote SP Mode is selected in the SP Mode parameter.
(2) This setting will be ignored for position-proportional model.
(3) This setting will be ignored for standard control or position-proportional
control.
(4) This parameter will be displayed only when the is a potentiometer input
for a position-proportional model.
■ Related Parameter
Transfer output type (initial setting level): Page 235
This parameter selects the output type for linear current outputs.
• When control output 1 or control output 2 is a current output, select either
4 to 20 mA or 0 to 20 mA as the output type.
tr-h Transfer Output Upper Limit
A transfer output or linear voltage
output must be supported.
The Transfer Output Type parameter
must not be set to OFF.
tr-l Transfer Output Lower Limit
Function
Setting
Transfer output
type
Setting range Default Unit
Transfer
output lower
limit
Transfer
output upper
limit
Set point (See
note 1.)
SP lower limit to SP upper limit SP lower limit SP upper limit EU
Set point during
SP ramp
SP lower limit to SP upper limit
PV Temperature Input setting range lower limit
to input setting range upper
limit
Input setting
range lower
limit
Input setting
range upper
limit
Analog Analog scaling lower limit to
analog scaling upper limit
Scaling lower
limit
Scaling upper
limit
MV monitor
(heating) (See
note 2.)
Standard −5.0 to 105.0 0.0 100.0 %
Heating/
cooling
0.0 to 105.0
MV monitor
(cooling) (See
note 3.)
0.0 to 105.0
Valve opening
(See note 4.)
Position-pro-
portional
−10.0 to 110.0
See
See
o1-t Linear Current Output
The E5CN-H must be used, and the
control output must be a current out-
put.
